Transformatorul cufundat cu ulei de 35kV SGOB 1600KVA 35KV este un dispozitiv de transformare a puterii de înaltă performanță, conceput pentru o distribuție de energie electrică eficientă și fiabilă în diferite aplicații industriale, comerciale și de utilitate. Acest transformator combină inginerie avansată cu o construcție robustă pentru a asigura servicii de lungă durată și performanțe optime în condiții operaționale diverse.
The SGOB 1600kva 35kv Oil Immersed Transformer is a high-efficiency power transformation solution designed for robust and reliable performance in diverse electrical systems. With a rated power of 1600kVA and a voltage rating of 35kV, this transformer is ideal for medium-voltage applications in industrial, commercial, and utility sectors.
The oil-immersed design provides excellent thermal management and insulation, ensuring the transformer operates within safe temperature limits and minimizing energy loss. This contributes to enhanced system efficiency and extends the transformer's lifespan.
Constructed from high-quality materials, the SGOB 1600kva 35kv Oil Immersed Transformer is built to withstand environmental factors and maintain operational stability over time. It features comprehensive safety mechanisms, including over-temperature protection and short-circuit prevention, to safeguard personnel and equipment.
The compact design of the SGOB 1600kva 35kv Oil Immersed Transformer allows for easy installation in both new and existing electrical setups, making it a versatile solution for a range of applications. It is suitable for use in power plants, industrial facilities, commercial buildings, and renewable energy systems, among others.
Key attributes
Industry-specific attributes
| Phase | Three |
Other attributes
| Place of Origin | Shanghai, China |
| Brand Name | SGOB |
| Model Number | S11-M-10000/10 |
| Coil Number | 3 |
| application | Power Distribution |
| Coil Structure | TOROIDAL |
| Type | Oil Transformer |
| Standard | IEC60076/GB1094 |
| Certification | ISO9001-2015/ISO14001-2004/OHSMS18000 |
| Rated Capacity | 1000KVA |
| Frequency | 50Hz/60Hz |
| Votage | 0.1kv-36kv |
| Coil Material | 100% Copper/Aluminum |
| Connection Symbol | Dyn11/Yyn0 |
| No Load Loss | 11.6kw |
| Impendence | 7.5% |
Packaging and delivery
| Packaging Details | Vacuum Wooded Case |
| Port | Shanghai |
| Selling Units: | Single item |
| Single package size: | 382X132X272 cm |
| Single gross weight: | 20000.000 kg |
Supply Ability
| Supply Ability | 5000 Set/Sets per Year |
